BASOO BS-220BX 170F Gasoline Engine – 212 cc
212 cc · Single cylinder · Four-stroke · OHV · Air-cooled
A 212 cc 170F-family gasoline engine with a horizontal output-shaft layout. Specify BASOO model BS-220BX for equipment integration, replacement assessment or a trade quotation.
Product Description
170F gasoline engine
The BASOO BS-220BX is a 212 cc gasoline engine built around the 170F engine family. Its single-cylinder, four-stroke layout provides a self-contained power unit for engine-driven equipment, with the drive connection selected to suit the machine.
Engine design
- Overhead-valve layout: intake and exhaust valves are located in the cylinder head.
- Forced-air cooling: engine-driven airflow removes heat from the cylinder and head without a liquid-coolant circuit.
- Horizontal output shaft: the engine connects to driven equipment through a compatible coupling, pulley or other specified drive arrangement.
- Four-stroke operation: intake, compression, combustion and exhaust take place over separate piston strokes.
Typical 170F applications
The 170F engine family is commonly used in water-pump sets, pressure washers, compact generating sets and other small engine-driven machinery. The appropriate engine configuration depends on the equipment’s power demand, working speed and mechanical connection.
Technical specifications
| Product model | BS-220BX |
|---|---|
| Engine code | 170F |
| Fuel type | Gasoline (petrol) |
| Displacement | 212 cc |
| Cylinder configuration | Single cylinder |
| Operating cycle | Four-stroke |
| Valve arrangement | Overhead valve (OHV) |
| Cooling system | Forced-air cooling |
| Output-shaft orientation | Horizontal |
Weight and packaging
| Net weight | 14 kg |
|---|---|
| Gross weight | 15 kg |
| Carton dimensions | 475 × 440 × 520 mm |
Equipment integration
Match the required power and torque at the machine’s operating speed, then check the output-shaft diameter, usable length, keyway or thread, rotation and mounting-hole pattern. Displacement alone does not establish interchangeability with another engine.
Starting and drive configuration
170F-family engines are produced in recoil-start and electric-start versions. Specify the starting arrangement and drive connection required for your equipment in the quotation request; availability and supplied components depend on the ordered configuration.
BS-220B and BS-220BX
BS-220B and BS-220BX are separate BASOO product models in the 212 cc range. Use the complete BASOO product code on enquiries and orders; a shared 170F engine designation does not specify the complete starting, shaft or supplied-equipment configuration.
Request a trade quotation
Reference BS-220BX and include your order quantity, destination country, equipment application and required starting and shaft configuration. Add any packaging, labelling or documentation requirements to the enquiry.
Additional Information
| Product model | BS-220BX |
|---|---|
| Engine code | 170F |
| Fuel type | Gasoline (petrol) |
| Cylinder configuration | Single cylinder |
| Operating cycle | Four-stroke |
| Displacement | 212 cc |
| Net weight | 14 kg |
| Gross weight | 15 kg |
| Carton dimensions | 475 × 440 × 520 mm |
| Valve arrangement | Overhead valve (OHV) |
| Cooling system | Forced-air cooling |
| Output-shaft orientation | Horizontal |
