BASOO BS-6500i0X 3.5 kW Inverter Generator
BASOO BS-6500i0X inverter generator: 3.5 kW rated, 3.8 kW maximum, 223 cc engine and 15 L tank. View specifications and request a quote.
Product Description
3.5 kW inverter power with a 15 L fuel tank
The BASOO BS-6500i0X offers 3,500 W rated output and 3,800 W maximum output, with a 223 cc BS-170 engine. It provides a step up in listed rated power from the BS-5500i0X while retaining a 15 L fuel tank.
The open frame surrounds the engine and control panel, with a digital meter, Eco switch and status indicators positioned at the front. The specified net weight is 42 kg. Compare this model when your planned running load requires more than the smaller 3 kW unit can provide.
Key features
- 3.5 kW rated output: use the 3,500 W rating as the reference for the planned running load.
- 3.8 kW maximum output: the 3,800 W upper power rating is stated separately from rated output.
- 223 cc BS-170 engine: the engine and displacement specified for this model.
- 15 L fuel tank: clear capacity information for comparing generator configurations.
- Digital meter and Eco control: front-panel controls with low-oil, overload and output indicators.
Technical specifications
| Specification | Details |
|---|---|
| Model | BS-6500i0X |
| Product type | Inverter Generator |
| Rated output | 3,500 W (3.5 kW) |
| Maximum output | 3,800 W (3.8 kW) |
| Alternator size | Ø160 × 140 mm |
| Output voltage | 220–230 V |
| Frequency | 50 Hz |
| Engine model | BS-170 |
| Displacement | 223 cc |
| Fuel tank capacity | 15 L |
| Net weight | 42 kg |
| Gross weight | 44 kg |
| Box dimensions | 530 × 320 × 480 mm |
Choosing the right generator
Compare the combined running demand of your equipment with the rated output, and check any additional starting requirements separately. Match the supplied voltage, frequency, socket configuration and equipment requirements before ordering. Fuel tank capacity alone does not establish runtime; request fuel-consumption or runtime data at your intended load.
Frequently asked questions
Is maximum output the normal running rating?
No. The rated output is 3,500 W; the maximum figure is 3,800 W. Size the normal running load against the rated figure and confirm the permitted starting load for the equipment you intend to connect.
What should I confirm for electronic equipment?
Request the voltage-regulation and total harmonic distortion (THD) specifications, then compare them with the connected equipment’s requirements. Ask BASOO to confirm these performance figures, which are not specified in this product table.
Request a quotation
Send BASOO the model BS-6500i0X, quantity and destination market, together with your equipment list and intended load. Confirm the required output voltage and socket arrangement, starting system and included accessories with your quotation.
Request a quotation for the BS-6500i0X · Browse inverter generators
Additional Information
| Model | BS-6500i0X |
|---|---|
| Product type | Inverter Generator |
| Rated output | 3,500 W (3.5 kW) |
| Maximum output | 3,800 W (3.8 kW) |
| Alternator size | Ø160 × 140 mm |
| Output voltage | 220–230 V |
| Frequency | 50 Hz |
| Engine model | BS-170 |
| Displacement | 223 cc |
| Fuel tank capacity | 15 L |
| Net weight | 42 kg |
| Gross weight | 44 kg |
| Box dimensions | 530 × 320 × 480 mm |
