BASOO BS-80HX 3-inch High-Pressure Gasoline Water Pump
3-inch inlet · 15 hp 190F engine. BASOO BS-80HX with 100 L/min maximum flow and 90 m maximum head for a correctly matched water-transfer installation.
Product Description
Water delivery for greater head
The BASOO BS-80HX combines a 3-inch inlet with a 15 hp 190F engine for water-transfer planning beyond a fixed electrical supply. Its specified maximum head of 90 m makes it a candidate for installations with greater elevation or pressure requirements. Its 38 kg net weight is useful when planning transport and placement.
Product highlights
- 3-inch inlet: 80 mm inlet specification for matching the suction hose and fittings.
- 15 hp engine: 190F power unit with a specified operating speed of 3,600 rpm.
- Up to 90 m head: assess the pump against the flow required at your operating head.
- Suction lift: listed at 8 m; keep the suction line short and account for site conditions.
Technical specifications
| Product model | BS-80HX |
|---|---|
| Fuel | Gasoline (petrol) |
| Engine model | 190F |
| Engine rated output | 15 hp |
| Specified speed | 3,600 rpm |
| Inlet size | 80 mm (3-inch nominal) |
| Maximum flow | 100 L/min |
| Maximum head (lift) | 90 m |
| Maximum suction lift | 8 m |
Weight and packaging
| Net weight | 38 kg |
|---|---|
| Gross weight | 39 kg |
| Carton dimensions | 600 × 440 × 440 mm |
Choosing the right setup
Evaluate this pump for water transfer to higher elevations and for irrigation systems that require greater head. Determine the total head, hose friction and required flow before selecting a model. Request a performance curve to confirm the available delivery at the intended operating point.
Common questions
Will it deliver maximum flow at maximum head?
No. Maximum flow and maximum head describe different operating points. Actual delivery depends on total head and pipe losses; request the pump’s performance curve for the flow at your required head.
What should I check before ordering?
Confirm inlet and outlet fitting details, liquid compatibility, suction conditions, included hoses and accessories, and the engine starting arrangement. Provide the site elevation, hose lengths and required delivery rate.
Request a quotation
Send model BS-80HX, your quantity, destination market and application details to BASOO. Include the required flow, delivery height and hose arrangement so the supplied configuration can be checked.
Request a quotation or technical details · Browse water pumps
Additional Information
| Product model | BS-80HX |
|---|---|
| Fuel | Gasoline (petrol) |
| Engine model | 190F |
| Engine rated output | 15 hp |
| Specified speed | 3,600 rpm |
| Inlet size | 80 mm (3-inch nominal) |
| Maximum flow | 100 L/min |
| Maximum head (lift) | 90 m |
| Maximum suction lift | 8 m |
| Net weight | 38 kg |
| Gross weight | 39 kg |
| Carton dimensions | 600 × 440 × 440 mm |
